Construction

Standard Maximum Width: 20'

Standard Maximum Height: 14’

Aluminum construction

Extruded aluminum slats

Features

Provides security against entry or theft with slide bolts or cylinder locks available

Interlocking slats constructed of .05" mill aluminum

Comes pre-assembled for easy installation

10' door coiling up into a 8" square hood

At 14' high, our tallest doors wrap into a 10" square hood

Compact aluminum bottom bar with a vinyl bulb seal

Options

Perforation and fenestration (full curtain or partial curtain)

Interior crank or tube motor with crank for emergency egress manual override

197 RAL powder coat colors or custom color to match architect specifications

Cylinder lock: pad-lockable slide bolt option, locking options for manual or crank operation only

Bottom bar step angle attachment

Colors

Standard powder coat colors (white, almond, silver, bronze)

Available in 197 RAL colors and can be custom matched to architect specifications

Wood grain powder coat colors (barrel oak, dark barrel oak, light maple, natural pine, rustic alder, and winchester cherry)

Brochure

Wayne Dalton Security Shutter Model 523 Brochure
