TNR Model HDXL6/HDXL9
Strongly built to withstand even the most challenging commercial and industrial environments, TNR Models HDXL6 and HDXL9 are suited for openings up to 55' wide and 35' high. These extra large rubber doors are virtually indestructible and available with a variety of customizable options.
Product Specs
Construction
- 1/4" black SBR rubber with polyester core weave
- Self-supporting channel steel C10 and flat bar mounting assembly
- Frame mounted thru-beam photoelectric sensor
- Bottom bar with rubber loop
Features
- Withstand temperatures ranging from -4°C to 80°C
- Sleek profile and lack of hinges, cables, pulley or tension springs help facilitate easy installation
- High-Efficiency Heligear Head (HG) Operator with multi-function PLC panel
- Door speed of up to 12" per second
- Counterbalance spring assembly cycle rating of 50,000
Options
- Access controls and specialty functions
- Hoods and travelling windbar
- Colours and window options
- MSHA-rated self-extinguishing curtains
Brochures
Highlights
| Material | Aluminum |
|
Insulation Value ? R0-R6 = 1 star | ★ |
| Uses | High Performance |
